ACF451832-681-TD01 TDK Corporation ACF451832-681-TD01 Real Image ACF451832-681-TD01 real image
Same model may have multiple batches, images only for reference.
ACF451832-681-TD01 TDK Corporation ACF451832-681-TD01 Real Image ACF451832-681-TD01 real image
ACF451832-681-TD01 TDK Corporation ACF451832-681-TD01 Real Image ACF451832-681-TD01 real image
Same model may have multiple batches, images only for reference.

ACF451832-681-TD01

Part No ACF451832-681-TD01
Manufacturer TDK Corporation
Catalog EMI/RFI Filters (LC, RC Networks)
Description EMI Filter LC-Circuit 25dB 0.3A 50VDC Flat Style SMD T/R / FILTER LC(T) SMD
Datasheet
ACF451832-681-TD01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer TDK Corporation
Packaging Reel - TR
Status Not For New Designs
Type Low Pass
Filter Order 3rd
Technology LC (T-Type)
Number of Channels 1
Attenuation Value 25dB @ 75MHz to 160MHz
Resistance - Channel (Ohms) 0.15
Current 300mA
ESD Protection No
Temperature Range - Operating -25°C to 85°C
Applications Data Lines for Mobile Devices
Voltage Rating 50V
Mounting SMD (SMT)
Dimension 0.177" L x 0.126" W (4.50mm x 3.20mm)
Height 0.079" (2.00mm)
Win Source Part Number 007817-ACF451832-681-TD01
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name ACF
Introduction Date July 26, 2001
ECCN EAR99
Country of Origin Japan, United States of America
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian ACF451832-681-TD01 CAD Model

Description

Features and Benefits

  • High stability across temperature variants
  • High-frequency operation
  • Compact footprint

Applications

  • Microwave communication systems
  • Radar surveillance systems
  • Broadband RF applications

Additional Details

The ACF451832-681-TD01 provides high stability and efficient performance in a compact design, particularly suited for high-frequency and microwave applications. Its resilience across varying temperatures ensures consistent operation in challenging environments.
