ANT016008LCS2442MA2 Real Image ANT016008LCS2442MA2 Real Image
Same model may have multiple batches, images only for reference.
ANT016008LCS2442MA2 Real Image ANT016008LCS2442MA2 Real Image
ANT016008LCS2442MA2 Real Image ANT016008LCS2442MA2 Real Image
Same model may have multiple batches, images only for reference.

ANT016008LCS2442MA2

Part No ANT016008LCS2442MA2
Manufacturer TDK Corporation
Catalog RF Antennas
Description RF ANT 2.4GHZ CHIP SOLDER SMD / Multilayer Antenna
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TDK Corporation
Packaging Reel
Frequency Group UHF (2GHz ~ 3GHz)
Frequency (Center/Band) 2.4GHz
Frequency Range 2.4GHz ~ 2.484GHz
Antenna Type Chip
Number of Bands 1
VSWR 3
Gain 2.5dBi
Termination Solder
Mounting Style SMD
Height (Maximum) 0.016" (0.40mm)
Manufacturer Pack Quantity 4,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803191-ANT016008LCS2442MA2
Ultra Librarian 3D Model Ultra Librarian ANT016008LCS2442MA2 CAD Model

Description

The TDK Corporation ANT016008LCS2442MA2 is a chip antenna with SMD mounting style and solder termination.

  • Frequency Range: 2.4GHz ~ 2.484GHz
  • Frequency Group: UHF (2GHz to 3GHz)
  • Gain: 2.5dBi
  • VSWR: 3
  • Package Quantity: 4,000
