Same model may have multiple batches, images only for reference.

PV3-24-5

Name: PV3-24-5
Brand: TDK-Lambda Americas Inc.
SKU: 1351818
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	PV3-24-5
Manufacturer	TDK-Lambda Americas Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 3W / Isolated Module DC DC Converter 1 Output 5V 600mA 18V - 36V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	TDK-Lambda Americas Inc
Series	PV (3W)
Package	Bulk
Product Status	Last Time Buy
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	5V
Current - Output (Max)	600mA
Power (Watts)	3 W
Voltage - Isolation	500 V
Applications	ITE (Commercial)
Features	OCP
Temperature Range - Operating	-20°C ~ 70°C
Efficiency	77%
Mounting Type	Through Hole
Package / Case	10-SIP Module, 9 Leads
Size / Dimension	1.30" L x 0.33" W x 0.71" H (33.0mm x 8.5mm x 18.0mm)
Standard Package	1
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
California Prop 65	Warning Information
Win Source Part Number	1351818-PV3-24-5
Ultra Librarian 3D Model	Ultra Librarian PV3-24-5 CAD Model

Alternative Products

Description

The TDK-Lambda Americas Inc PV (3W) series isolated module DC DC converter from TDK-Lambda Americas Inc is a through-hole converter that comes with a size/dimension of 1.30" L x 0.33" W x 0.71" H (33.0mm x 8.5mm x 18.0mm).

Size / Dimension: 1.30" L x 0.33" W x 0.71" H (33.0mm x 8.5mm x 18.0mm)
Voltage - Isolation: 500V
Current - Output: 600mA
Power (Watts): 3W
Efficiency: 77%
Voltage - Input (Min): 18V
Voltage - Input (Max): 36V
Voltage - Output 1: 5V
Packaging: Bulk
Standard Package: 1
ECCN: EAR99
HTSUS: 8504.40.9580
