Same model may have multiple batches, images only for reference.

PXE30-48S12

Name: PXE30-48S12
Brand: TDK-Lambda Americas Inc.
SKU: 1349502
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	PXE30-48S12
Manufacturer	TDK-Lambda Americas Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 12V 30W / Isolated Module DC DC Converter 1 Output 12V 2.5A 36V - 75V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	TDK-Lambda Americas Inc
Series	PXE (30W)
Package	Tube
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	36V
Voltage - Input (Max)	75V
Voltage - Output 1	12V
Current - Output (Max)	2.5A
Power (Watts)	30 W
Voltage - Isolation	1.6 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OVP, SCP
Temperature Range - Operating	-40°C ~ 100°C
Efficiency	90%
Mounting Type	Through Hole
Package / Case	8-DIP Module, 6 Leads
Size / Dimension	2.00" L x 1.60" W x 0.40" H (50.8mm x 40.6mm x 8.6mm)
Base Product Number	PXE30
Standard Package	1
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
California Prop 65	Warning Information
Win Source Part Number	1349502-PXE30-48S12
Ultra Librarian 3D Model	Ultra Librarian PXE30-48S12 CAD Model

Alternative Products

Description

The PXE30-48S12 is a 30W isolated module DC-DC converter from TDK-Lambda Americas Inc.

Features: Remote On/Off, OCP, OVP, and SCP
Application: ITE (Commercial)
Voltage Isolation: 1.6 kV
Output: Single, 12V
Efficiency: 90%
Maximum Output Current: 2.5A
Mounting Type: Through Hole
Package: 8-DIP Module, 6 Leads
Temperature Range: -40°C to 100°C
ECCN: EAR99
REACH: Unaffected
HTSUS: 8504.40.9580
