The 1735690-1 is a Barrel Audio Connector manufactured by TE Connectivity. It is designed to provide a reliable connection for audio signals in various electronic devices and systems. These connectors are commonly used for connecting microphones, headphones, speakers, and other audio equipment.

Applications:

• Audio equipment
• Microphones
• Headphones
• Speakers
• Audio mixers
• Amplifiers
• Musical instruments

Features:

• 3.5mm Connector Size: Standard size for audio connections.
• Through Hole Mounting: Allows for secure attachment to printed circuit boards.
• Metal Shell: Provides mechanical protection and shielding against electromagnetic interference (EMI).
• Solder Termination: Ensures a strong and reliable electrical connection.
• Durable Construction: Designed to withstand frequent use and environmental factors.

Benefits:

• Reliable Audio Connection: Ensures clear and consistent audio signal transmission.
• Durable and Long-Lasting: Designed for frequent use and harsh environments.
• Easy to Install: Simple through-hole mounting and solder termination.
• EMI Shielding: Minimizes interference from external sources.
• Versatile Application: Suitable for a wide range of audio devices.

Additional Details:

The TE Connectivity 1735690-1 Barrel Audio Connector typically features a housing made of metal to provide robust mechanical protection and effective EMI shielding. The contacts are usually made of brass or bronze with plating to ensure good electrical conductivity and corrosion resistance. Key specifications include voltage rating, current rating, and contact resistance. This connector is designed to maintain signal integrity and minimize signal loss in audio applications. Proper soldering techniques are essential to ensure a reliable and long-lasting connection.
