Same model may have multiple batches, images only for reference.
5435802-3 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

5435802-3

Part No 5435802-3
Manufacturer TE Connectivity
Catalog DIP Switches
Description SWITCH PIANO DIP SPST 0.025A 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Circuit SPST
Number of Positions 4
Current Rating (Amps) 25mA
Voltage Rating 24VDC
Actuator Type Piano
Actuator Level Raised
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.290" (7.37mm)
Mounting Type Through Hole, Right Angle
Termination Style PC Pin
Pitch 0.100" (2.54mm), Full
Washable No
Temperature Range - Operating -55°C ~ 105°C
Package Tube
Supply and Demand Status Limited
Win Source Part Number 1552713-5435802-3
Ultra Librarian 3D Model Ultra Librarian 5435802-3 CAD Model
