ADS124S08IPBSR

Name: ADS124S08IPBSR
Brand: Texas Instruments
SKU: 806416
Availability: InStock
Rating: 5 (605 reviews)

Part No	ADS124S08IPBSR
Manufacturer	Texas Instruments
Catalog	Data Acquisition - Analog to Digital Converters (ADC)
Description	IC ADC 24BIT SIGMA-DELTA 32LQFP / PGA and Voltage Reference
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $6.624

Quantity

Unit Price

Ext. Price

$8.7610

$52.566

14+

$7.1890

$100.646

22+

$6.9640

$153.208

30+

$6.7400

$202.200

39+

$6.5150

$254.085

52+

$5.8410

$303.732

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 18,003 pieces

MOQ: 6 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Manufacturer	Texas Instruments
Packaging	Reel
Number of Bits	24
Sampling Rate (Per Second)	4k
Number of Inputs	12
Input Type	Single Ended
Data Interface	SPI
Configuration	MUX-PGA-ADC
Number of A/D Converters	1
Architecture	Sigma-Delta
Reference Type	External, Internal
Voltage - Supply, Analog	2.7V ~ 5.25V
Voltage - Supply, Digital	2.7V ~ 3.6V
Features	PGA
Temperature Range - Operating	-50°C ~ 125°C
Manufacturer Package	32-LQFP
Supplier Device Package	32-LQFP (5x5)
Mounting Style	Surface Mount
Manufacturer Pack Quantity	1,000
MSL Level	3 (168 Hours)
Popularity	Medium
Fake Threat In the Open Market	45 pct.
Supply and Demand Status	Balance
Win Source Part Number	806416-ADS124S08IPBSR

Description

Product Overview: Texas Instruments ADS124S08IPBSR

The ADS124S08IPBSR from Texas Instruments is a precision, 24-bit, analog-to-digital converter (ADC) designed with the needs of sensor measurement and industrial control applications in mind. This high-performance ADC offers a flexible input multiplexer (MUX), a built-in programmable gain amplifier (PGA), and an internal reference to provide a comprehensive solution for complex data acquisition scenarios.

Key Features

High Resolution: With 24-bit resolution, the ADS124S08IPBSR ensures high-precision measurements, making it ideal for applications requiring accurate data readings such as temperature, pressure, and weight measurement.
Flexible Input MUX: The device features a versatile input multiplexer that supports 11 differential or 19 single-ended inputs, allowing for a wide range of sensor types and configurations to be connected directly to the ADC.
Programmable Gain Amplifier: The integrated PGA provides gains ranging from 1 to 128, enhancing the ADC's ability to detect small signal variations, which is crucial in sensor applications.
Internal Reference: The ADS124S08IPBSR includes an internal 2.5V reference, reducing the need for external components and simplifying the design process.
Data Rate: It supports data rates up to 2 kSPS, offering a good balance between speed and resolution to cater to various application requirements.
Interface: The device is equipped with a SPI-compatible serial interface, facilitating easy communication with microcontrollers and digital systems.
Compact Package: Available in a compact QFN-32 package, it is suitable for space-constrained applications.

Applications

The ADS124S08IPBSR is a versatile component that can be used across a broad range of applications, including:

Industrial process controls
Temperature measurement systems
Bridge sensor-based systems for pressure, strain, and force measurements
Weigh scales
Battery monitoring
Medical instrumentation

With its robust feature set, the ADS124S08IPBSR from Texas Instruments stands out as a reliable choice for engineers and designers looking to implement precise data acquisition systems with minimal additional circuitry.
