ADS8688AIDBT

Part No ADS8688AIDBT
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 16BIT SAR 38TSSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 5 Weeks
Features 16 Bit Analog to Digital Converter 8 Input 1 SAR 38-TSSOP
Manufacturer Texas Instruments
Package Tube
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package 38-TFSOP (0.173", 4.40mm Width)
Case / Package 38-TSSOP
Family Name ADS8688
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-42530-5, -296-42530-5-ND
Quantity per package 50
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 860468-ADS8688AIDBT
Ultra Librarian 3D Model Ultra Librarian ADS8688AIDBT CAD Model

Description

Product Overview: Texas Instruments ADS8688AIDBT

The ADS8688AIDBT is a state-of-the-art, precision analog-to-digital converter (ADC) from Texas Instruments, designed to meet the rigorous demands of industrial and instrumentation applications. This high-performance device features a 16-bit SAR ADC, providing a perfect balance between high speed and high resolution to ensure accurate data acquisition in a variety of systems.

Key Features

  • Resolution: 16-bit SAR ADC, ensuring precise and accurate signal conversion.
  • Sampling Rate: Offers a maximum sampling rate of 500 kSPS, allowing for the capture of fast transient signals.
  • Input Range: Bipolar input range of ±10.24 V and unipolar ranges up to 10.24 V, providing flexibility for various signal types.
  • Channels: Features eight pseudo-differential or four differential input channels, enabling the monitoring of multiple signals.
  • Interface: SPI-compatible serial interface for easy connection to microcontrollers and DSPs.
  • Integrated Features: Includes an internal reference, a temperature sensor, and a GPIO for added functionality without the need for external components.
  • Package: Available in a compact 38-pin TSSOP package, ideal for space-constrained applications.

Applications

The ADS8688AIDBT is versatile and can be used in a wide array of applications, including:

  • Industrial automation and process control
  • Motor control and power management systems
  • Data acquisition systems (DAQ)
  • Medical instruments for precise measurements
  • Test and measurement equipment

Performance and Reliability

Texas Instruments is known for its commitment to performance and reliability, and the ADS8688AIDBT is no exception. It ensures low power consumption, high accuracy, and excellent thermal performance, making it suitable for critical applications where precision is paramount. Furthermore, the device is supported by Texas Instruments' comprehensive technical resources, including datasheets, application notes, and evaluation modules, to facilitate rapid development and integration into your projects.
