Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Type Programmable Timer
Count 65536
Frequency 100kHz
Supply Voltage - Operating 3 V to 20 V
Temperature Range - Operating -55°C to 125°C
Case / Package 14-PDIP
Mounting Through Hole
Win Source Part Number 006235-CD4541BE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Clock & Timing
Family Name CD4541
Introduction Date January 01, 2002
ECCN EAR99
Country of Origin Malaysia, Malaysia, Mexico, Mexico
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian CD4541BE CAD Model

Description

CD4541BE - Programmable Timer IC

The CD4541BE provides reliable digital timing solutions with its programmable timer characteristics. Its robust design makes it ideal for various applications demanding timing accuracy and durability.

  • Consumer electronics
  • Digital clocks and timers
  • Motor control systems
  • Temperature control units

Features and Benefits:

  • Broad input voltage range enhances adaptability
  • Adjustable oscillator frequency suits multiple timing scenarios
  • Built-in binary counter/divider for precision time management
  • Low power dissipation keeps circuitry efficient and cool

This part is perfect for implementing digital delays and oscillators in electronic systems, offering consistency and performance across various temperatures and environments.
