Products specifications

Manufacturer Texas Instruments
Packaging Reel
Function Latch
Technology Hall Effect
Polarization Either
Sensing Range 3.3mT Trip, -3.3mT Release
Test Condition -40°C ~ 85°C
Supply Voltage (V) 1.65V ~ 5.5V
Current - Supply (Maximum) 5mA
Current - Output (Maximum) 5mA
Output Type Push-Pull
Features Temperature Compensated
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 4-XFDFN Exposed Pad
Supplier Device Package 4-X2SON (1.1x1.4)
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 806418-DRV5012AEDMRR
Ultra Librarian 3D Model Ultra Librarian DRV5012AEDMRR CAD Model

Description

The DRV5012AEDMRR from Texas Instruments is a cutting-edge Hall effect sensor designed for cost-efficient and reliable sensing in a variety of applications. This magnetic sensor device responds to magnetic fields to determine the presence of a magnetic object, making it ideal for position sensing, rotation detection, and speed measurement.

Key Features:

  • Supply Voltage Range: The DRV5012 operates from a 2.5V to 38V supply voltage range, ensuring compatibility with a wide array of applications and systems.
  • Output: It provides a digital latch output, which retains the state of the magnetic field detection until the opposite magnetic pole is detected, offering a reliable and stable sensing solution.
  • Temperature Range: With an operating temperature range of -40°C to 125°C, the DRV5012 is suitable for harsh environments and can maintain performance across a broad spectrum of conditions.
  • Power Consumption: The device is optimized for low-power operation, making it suitable for battery-powered and energy-sensitive applications.
  • Package: The DRV5012AEDMRR is available in a compact SOT-23 package, which is space-efficient and ideal for designs where board space is at a premium.
  • Robustness: It is designed to be robust against common issues such as stray magnetic fields and physical misalignment, ensuring accurate and reliable operation.

Applications:

The DRV5012 is versatile and can be implemented in various sectors, including:

  • Industrial equipment
  • Consumer electronics
  • Automotive systems
  • Position and rotation sensing
  • Motor control

With its robust design, the DRV5012AEDMRR from Texas Instruments is an excellent choice for designers seeking a reliable and efficient Hall effect sensor. Its ease of integration, coupled with Texas Instruments' support and resources, makes it a go-to component for both prototyping and mass production.
