INA282AIDR Real Image INA282AIDR real image164 INA282AIDR Real Image1 INA282AIDR Real Image2 INA282AIDR Real Image3 INA282AIDR Real Image4
Same model may have multiple batches, images only for reference.
INA282AIDR Real Image INA282AIDR real image164 INA282AIDR Real Image1 INA282AIDR Real Image2 INA282AIDR Real Image3 INA282AIDR Real Image4
INA282AIDR Real Image INA282AIDR real image164 INA282AIDR Real Image1 INA282AIDR Real Image2 INA282AIDR Real Image3 INA282AIDR Real Image4
Same model may have multiple batches, images only for reference.

INA282AIDR

Part No INA282AIDR
Manufacturer Texas Instruments
Catalog PMIC - Current Regulation/Management
Description SP Amp Current Shunt Monitor Single 18V Automotive 8-Pin SOIC T/R / IC CURRENT SHUNT MONITOR 8SOIC
Datasheet
INA282AIDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Current Monitor
Sensing Method High/Low-Side
Accuracy ±0.4%
Voltage - Input -14 V to 80 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 017301-INA282AIDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Automotive, Power Management
Family Name INA282
Introduction Date March 01, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian INA282AIDR CAD Model

Description

The INA282AIDR is a high-quality, high-performance, bidirectional current and power monitor from Texas Instruments.

  • Common-Mode Voltage Range: -14V to +80V
  • Accuracy: ±1.5% maximum gain error
  • Quiescent Current: 900 µA (typical)
  • Bidirectional: Yes
  • Package: 8-pin SOIC
