LM317KTTR Real Image LM317KTTR real image1301 LM317KTTR Real Image1 LM317KTTR Real Image2 LM317KTTR Real Image3
Same model may have multiple batches, images only for reference.
LM317KTTR Real Image LM317KTTR real image1301 LM317KTTR Real Image1 LM317KTTR Real Image2 LM317KTTR Real Image3
LM317KTTR Real Image LM317KTTR real image1301 LM317KTTR Real Image1 LM317KTTR Real Image2 LM317KTTR Real Image3
Same model may have multiple batches, images only for reference.

LM317KTTR

Part No LM317KTTR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR ADJ 1.5A DDPAK
Datasheet
LM317KTTR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 40V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 37V
Output Current 1.5A
PSRR 80dB to 65dB (120Hz)
Control Protection Features Over Circuit, Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 37 V
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 107756-LM317KTTR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LM317
Introduction Date January 01, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM317KTTR CAD Model

Description

The LM317KTTR is a high-quality adjustable voltage regulator from Texas Instruments, a renowned global semiconductor company.

  • Regulator Type: adjustable 3-terminal positive-voltage regulator
  • Current Supply: capable of supplying more than 1.5 A
  • Output Voltage Range: 1.25 V to 37 V
  • External Resistors: only two external resistors to set the output voltage
  • Features: internal current limiting, thermal shutdown, and safe-area compensation
  • Applications: local, on-card regulation
  • Applications: programmable output regulator
  • Applications: precision current regulator
  • Feature: thermal overload protection
  • Protection: safe-area protection for the output transistor
  • Feature: output transistor safe-area compensation
  • Feature: output capacitor which improves transient response
  • Package Type: TO-263
  • Thermal Resistance: low
  • Footprint: small
