LM3526M-H/NOPB Real Image LM3526M-H/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM3526M-H/NOPB Real Image LM3526M-H/NOPB Real Image
LM3526M-H/NOPB Real Image LM3526M-H/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM3526M-H/NOPB

Part No LM3526M-H/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC USB POWER SWITCH 8-SOIC
Datasheet
LM3526M-H/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Switch Type USB Switch
Number of Outputs 2
Output Type P-Channel
Voltage - Load 2.7 V to 5.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 500mA
Rds On (Typ) 100 mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 8-SOIC
Win Source Part Number 006116-LM3526M-H/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM3526M-H/NOPB CAD Model

Description

The LM3526M-H/NOPB is a high-performance, dual-port USB power switch and over-current protection device manufactured by Texas Instruments, a global semiconductor design and manufacturing company.

  • Continuous Current: Up to 2.1A per switch
  • Internal Current Limit: Prevents damage to the host device.
  • Fault Flag Functions: Provide over-current and thermal protection.
  • Enable Input: Allows the power switch to be enabled or disabled as required.
  • Package: Compact 16-pin SOIC package
  • Operating Temperature Range: -40°C to 125°C
