LM5009ASD

Name: LM5009ASD
Brand: Texas Instruments
SKU: 617504
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	LM5009ASD
Manufacturer	Texas Instruments
Catalog	PMIC - Voltage Regulators - DC DC Switching Regulators
Description	SWITCHING REG, 0.36A
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - DC DC Switching Regulators
Mfr	National Semiconductor (TI)
Package	Bulk
Product Status	Active
Function	Step-Down
Output Configuration	Positive
Topology	Buck
Output Type	Adjustable
Number of Outputs	1
Voltage - Input (Min)	6V
Voltage - Input (Max)	95V
Voltage - Output (Min/Fixed)	2.5V
Voltage - Output (Max)	95V
Current - Output	150mA
Frequency - Switching	50kHz ~ 1.1MHz
Synchronous Rectifier	No
Temperature Range - Operating	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	8-WDFN Exposed Pad
Supplier Device Package	8-WSON (4x4)
Base Product Number	LM5009
Standard Package	1,000 pcs
MSL Level	3 (168 Hours)
REACH Status	Vendor Undefined
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	617504-LM5009ASD
Ultra Librarian 3D Model	Ultra Librarian LM5009ASD CAD Model

Alternative Products

Description

The LM5009ASD is a DC-DC switching regulator from National Semiconductor (TI) that is designed for power management applications.

Type: Step-down regulator
Output Type: Adjustable
Supply Voltage Range: 6V to 95V
Output Current: 150mA
Frequency Switching Range: 50kHz to 1.1MHz
Output Configuration: Single output
Package: 8-WDFN exposed pad
Mounting: Surface mount
Temperature Range: -40°C to 125°C
Market Status: Active
