Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 1.3 V/μs
Gain Bandwidth Product (GBP) 1.5MHz
Current - Input Bias 0.02pA
Voltage - Input Offset 110μV
Operating Supply Current 2.6mA
Channel Output Current 30mA
Supply Voltage - Operating 3 V to 15.5 V, ±1.5 V to 7.75 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 082872-LMC6484IM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Signal Processing, Medical
Ultra Librarian 3D Model Ultra Librarian LMC6484IM CAD Model

Description

The is a high-performance, low-power CMOS quad operational amplifier from Texas Instruments. It offers a broad voltage range from 2.5V to 15.5V and a high input impedance to minimize loading on input signals.

  • Rail-to-Rail Output Swing: Provides a wide dynamic range and is suitable for driving ADCs or buffering DACs
  • Input Bias Current: Low, making it suitable for high-impedance applications and extending battery life in portable devices
  • Slew Rate: 1.1V/µs, for fast and precise operation
  • Package: 14-pin SOIC
  • Operating Temperature Range: -40°C to 85°C
  • Features: High input impedance, low power consumption, and excellent noise performance, making it suitable for audio, instrumentation, and other high-demand applications
