The LMZ10500SH/NOPB is a nano module from Texas Instruments that offers an integrated and efficient power management solution. This compact component is designed to simplify the design of power supply systems, making it an ideal choice for space-constrained applications.

Key Features

• Output Voltage Range: The LMZ10500SH/NOPB provides an adjustable output voltage range from 0.8V to 3.6V, enabling it to support a variety of low-voltage applications.
• High Efficiency: With an efficiency of up to 90%, this power module ensures minimal energy loss during the voltage conversion process, which is crucial for battery-powered devices.
• Integrated Inductor: The inclusion of an integrated inductor simplifies the design process by reducing the number of external components required, thus saving board space and reducing overall system complexity.
• Low Profile: The nano module comes in a small outline, no-lead (SON) package with a footprint of just 2.5mm x 3mm and a low profile of 1.2mm, making it suitable for portable electronics where space is at a premium.
• Input Voltage Range: It operates over a wide input voltage range from 2.7V to 5.5V, accommodating various power sources including single-cell lithium-ion batteries.
• Thermal Performance: The LMZ10500SH/NOPB is designed with excellent thermal performance in mind, featuring a power-good output for power sequencing and protection features such as over-temperature and over-current protection.

Applications

The versatility of the LMZ10500SH/NOPB makes it suitable for a broad range of applications, including but not limited to:

• Portable and battery-powered devices
• Space-constrained applications such as wearables and IoT devices
• Point-of-load conversions for FPGAs, DSPs, and microprocessors

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the LMZ10500SH/NOPB is no exception. This product is RoHS compliant and is designed to meet the rigorous standards set by the industry, ensuring reliable performance in a variety of conditions.
