Products specifications

Category Integrated Circuits (ICs) - Interface - Specialized
Mfr Texas Instruments
Package Tube
Product Status Not For New Designs
Applications Testing Equipment
Interface IEEE 1149.1
Voltage - Supply 3V ~ 3.6V
Package / Case 48-TFSOP (0.240", 6.10mm Width)
Supplier Device Package 48-TSSOP
Mounting Type Surface Mount
Base Product Number SCANSTA111
Standard Package 38 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 664441-SCANSTA111MT
Ultra Librarian 3D Model Ultra Librarian SCANSTA111MT CAD Model

Description

The SCANSTA111MT by Texas Instruments is a state-of-the-art boundary-scan controller designed to facilitate the testing and programming of digital circuit boards and systems. This advanced device is an integral component for engineers looking to implement JTAG (Joint Test Action Group) boundary-scan technologies in their development and manufacturing processes.

Key Features

  • High-Performance JTAG Interface: The SCANSTA111MT offers a high-speed IEEE 1149.1-compliant interface, ensuring compatibility with a broad range of boundary-scan-capable chips and systems.
  • Multi-TAP Support: With the capability to control multiple TAPs (Test Access Ports), this controller streamlines the testing and programming of complex multi-chip modules and densely populated boards.
  • Advanced Diagnostics: The device includes features for advanced diagnostics and fault isolation, which are critical for pinpointing issues quickly and accurately during the production and testing phases.
  • Flexible Integration: Its versatile design allows for easy integration into a variety of test fixtures and in-system programming environments, making it an ideal choice for both benchtop development and automated production lines.

Applications

The SCANSTA111MT is suitable for a wide array of applications, including:

  • Automated Test Equipment (ATE)
  • In-Circuit Testing (ICT)
  • Embedded System Programming
  • Complex Board-Level Diagnosis
  • System-Level Integration Testing

Technical Specifications

The device is packaged in a 80-TQFP (Thin Quad Flat Pack) and operates over a broad temperature range, making it reliable for use in various environmental conditions. Its technical specifications are designed to meet the rigorous demands of modern electronic testing and programming.

Ordering and Availability

The SCANSTA111MT is available for order directly from Texas Instruments or through authorized distributors. For detailed pricing, availability, and additional technical resources, including datasheets and support documentation, please visit the Texas Instruments website or contact your local sales representative.
