SG3524NE4 Texas Instruments SG3524NE4 real image
Same model may have multiple batches, images only for reference.
SG3524NE4 Texas Instruments SG3524NE4 real image
SG3524NE4 Texas Instruments SG3524NE4 real image
Same model may have multiple batches, images only for reference.

SG3524NE4

Part No SG3524NE4
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR MULT TOPOLOGY 16DIP
Datasheet
SG3524NE4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Transistor Driver
Purpose Step-Up, Step-Down, Step-Up/Step-Down
Number of Outputs 2
Output Phases 1
Supply Voltage - Operating 8 V to 40 V
Frequency - Switching 450kHz
Duty Cycle (Max) 45%
Synchronous Rectifier No
Clock Sync No
Control Features Current Limit, Frequency Control
Temperature Range - Operating 0°C to 70°C (TA)
Case / Package 16-PDIP
Win Source Part Number 211587-SG3524NE4
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SG3524NE4 CAD Model

Description

The SG3524NE4 from Texas Instruments is a versatile and high-performance integrated circuit (IC) specifically designed for power supply applications.

  • Operating Frequency Range: up to 300 kHz
  • Built-in Reference Voltage: 5V, trimmed to ±1%, capable of providing up to 100mA output current
  • Pulse-Width Modulation (PWM) Control Circuitry: complete
  • Package: 16-pin DIP (Dual In-line Package)
  • RoHS Compliant: yes
