SN65LVDS34DR Real Image SN65LVDS34DR Real Image
Same model may have multiple batches, images only for reference.
SN65LVDS34DR Real Image SN65LVDS34DR Real Image
SN65LVDS34DR Real Image SN65LVDS34DR Real Image
Same model may have multiple batches, images only for reference.

SN65LVDS34DR

Part No SN65LVDS34DR
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC DIFF RECEIVER H-S 8-SOIC
Datasheet
SN65LVDS34DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Receiver
Protocol LVDS
Number of Drivers/Receivers 0/2
Receiver Hysteresis 50mV
Data Rate 400Mbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 029591-SN65LVDS34DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN65LVDS34DR CAD Model

Description

The SN65LVDS34DR is a high-performance differential line receiver from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Technology: low-voltage differential signaling (LVDS)
  • Temperature Range: -40 to 85 degrees Celsius
  • Supply Voltage Range: 3V to 3.6V
  • Package: 8-pin SOIC package
  • Pinout: flow-through pinout
  • Data Signaling Rate: up to 630 Mbps
  • Quiescent power: typical of 0.12 mW when powered down (VCC = 3.3V)
  • Compliance: RoHS compliant and lead-free
  • Standard Compliance: TIA/EIA-644-A standard
