SN74AXC2T45DTMR - Texas Instruments

The SN74AXC2T45DTMR from Texas Instruments is a state-of-the-art, dual-bit, non-inverting bus transceiver that belongs to the AXC family, designed to provide seamless voltage level translation in mixed-voltage applications. This device is particularly suitable for systems that require a bidirectional asynchronous data bus to interface between different voltage nodes.

With its dual-supply voltage operation, the SN74AXC2T45DTMR can translate signals between two different logic levels ranging from 0.65 V to 3.6 V. This flexibility makes it an ideal component for interfacing between low-voltage microprocessors or microcontrollers and higher-voltage peripheral devices without the need for additional level shifting components.

Key Features:


• Wide Voltage Range: The device supports translation from 0.65 V to 3.6 V on both the A and B ports, allowing for versatile interfacing options.

• Low Power Consumption: The SN74AXC2T45DTMR is optimized for low-power operation, making it suitable for battery-powered and power-sensitive applications.

• High-Speed Data Transfer: It supports high-speed data transfer with over-voltage tolerance, ensuring reliable communication between devices.

• Direction Control: The direction of data flow is determined by the DIR input, providing flexibility in controlling the direction of the bus.

• Power-Off Protection: Inputs and outputs are equipped with power-off protection, which prevents damaging current backflow when the device is powered down.

• Small Package: The device comes in a compact DMT (VSSOP) package, which is ideal for space-constrained applications.

The SN74AXC2T45DTMR is designed for ease of use with a simple control interface. The output-enable (OE) input can disable the device so that the outputs are effectively in a high-impedance state. This feature is particularly useful in multi-master communication systems, where bus contention needs to be minimized.

Whether you're working on a multi-voltage platform, designing a system with various interfacing requirements, or simply in need of reliable level translation, the SN74AXC2T45DTMR from Texas Instruments is an excellent choice for ensuring compatibility and performance across different voltage domains.
