Product Overview: SN74CBTLV16211DL

The SN74CBTLV16211DL is a high-performance integrated circuit manufactured by Texas Instruments, designed to provide a low-voltage 24-bit bus switch with 12-bit bus inverters and 3-state outputs. This product falls under the category of switch ICs, specifically designed for applications that require the routing of signals with minimal propagation delay and low power consumption.

Key Features

• Low-Voltage Operation: The SN74CBTLV16211DL operates at a voltage range of 2.3V to 3.6V, making it suitable for low-voltage applications and ensuring compatibility with modern low-voltage logic levels.
• High Speed: The device boasts a quick switch speed, with a typical delay time of only 0.25 ns (max), facilitating high-speed signal switching without significant lag.
• Low Power Consumption: Designed for energy efficiency, this bus switch IC minimizes power consumption, making it ideal for power-sensitive designs.
• 24-Bit Bus Switch with 12-Bit Bus Inverters: The SN74CBTLV16211DL features a 24-bit bus for signal switching and 12-bit inverters for signal inversion, providing flexibility in signal routing and manipulation.
• 3-State Outputs: The inclusion of 3-state outputs allows for the disconnection of the outputs from the bus lines, effectively preventing back-driving and enabling multiple devices to share the same bus.

Applications

The SN74CBTLV16211DL is ideal for a variety of applications, particularly where high-speed and low-power signal switching is essential. It is commonly used in:

• Bus isolation and switching in servers and networking equipment
• Signal gating, where control of signal flow is required
• Level shifting applications to interface different voltage domains
• Hot-swapping and hot-docking operations in portable electronics

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the SN74CBTLV16211DL is no exception. It undergoes rigorous testing and quality control measures to ensure it meets industry standards and customer expectations.
