The SN74HC14DT is a versatile and high-performance hex inverter integrated circuit from Texas Instruments, designed to handle the demanding requirements of various digital applications. This device features six independent inverters with Schmitt-Trigger inputs, which are tailored to provide noise immunity and stable output transitions.

Key Features

• Logic Type: The SN74HC14DT is a hex inverter with Schmitt-Trigger inputs, providing enhanced signal conditioning for digital circuits.
• Operating Voltage: It operates over a wide range of supply voltages from 2V to 6V, making it suitable for interfacing with both TTL and CMOS logic levels.
• High Current Drive: This IC is capable of driving up to 10mA at the output, allowing it to drive larger loads or to be used in LED driving applications.
• Temperature Range: The device is designed to function over an extended temperature range, from -40°C to 85°C, ensuring reliability in various environmental conditions.
• Package: The SN74HC14DT is offered in an SOIC package with 14 pins, providing a compact footprint for space-constrained applications.

Applications

The SN74HC14DT is ideal for a multitude of electronic applications including, but not limited to:

• Wave shaping and signal processing
• Glitch removal on digital lines
• Logic level conversion
• High-speed logic gates

Quality and Reliability

Texas Instruments is renowned for its commitment to quality, and the SN74HC14DT is no exception. It is manufactured to the highest industry standards, ensuring that each chip delivers consistent performance and reliability. As part of the 74HC family, this product benefits from the rigorous testing and validation procedures that Texas Instruments is known for.

Ordering Information

For detailed ordering and shipping information, or to request samples of the SN74HC14DT, please visit the Texas Instruments official website or contact an authorized distributor. Ensure to reference the complete part number, including the 'DT' suffix, when placing an order to specify the SOIC package variant of the SN74HC14 hex Schmitt-Trigger inverters.
