The SN74LVC1G08DCKRG4 is a high-quality, single 2-input positive AND gate device designed and manufactured by Texas Instruments. This product is part of the TI’s SN74LVC1G08 series and is known for its exceptional performance and reliability.

The device functions as an independent gate and can perform the Boolean function Y = A • B or Y = A + B in positive logic. This versatile device is optimized for use in a wide range of applications, including personal electronics, industrial machinery, and telecommunications equipment.

The SN74LVC1G08DCKRG4 operates over a wide voltage range from 1.65 V to 5.5 V. It is characterized for operation from -40°C to 85°C. It also features inputs that are equipped with TI's proprietary Schmitt-trigger circuit, which allows it to be used in systems with slow or noisy inputs, improving system performance and reliability.

Furthermore, the SN74LVC1G08DCKRG4 is designed in a small SC70-5 package, making it ideal for space-constrained applications. It is also RoHS compliant and lead-free, reflecting Texas Instruments' commitment to environmentally friendly practices.

With its high drive capability, low power consumption, and excellent noise immunity, the SN74LVC1G08DCKRG4 is a robust and reliable choice for a wide range of digital logic applications. It is a testament to Texas Instruments' commitment to quality and innovation in the field of semiconductor technology.

Key Features:

• Operates From 1.65 V to 5.5 V
• Inputs Accept Voltages to 5.5 V
• Max tpd of 3.7 ns at 3.3 V
• ±24-mA Output Drive at 3.3 V
• Schmitt-Trigger Action Inputs
• Low Power Consumption
• SC70-5 Package
• RoHS Compliant and Lead-Free
