SN74LVC1G08DRLR

Part No SN74LVC1G08DRLR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE AND 1CH 2-INP SOT-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 10μA
Current - Output High, Low 32mA, 32mA
Max Propagation Delay @ V, Max CL 4ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-5
Dimension SOT-553
Win Source Part Number 139533-SN74LVC1G08DRLR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74LVC1G08DRLR CAD Model

Description

About SN74LVC1G08DRLR from Texas Instruments

The SN74LVC1G08DRLR is a high-performance, advanced chip from Texas Instruments, a renowned name in the electronics industry. This device is a single 2-input positive-AND gate, designed with advanced silicon-gate CMOS technology. It is a part of the LVC (Low-Voltage CMOS) series, which is known for its low power consumption and high-speed operation.

This product operates at a voltage range of 1.65 V to 5.5 V, making it suitable for a wide range of applications. It can support inputs from 5-V systems to 3.3-V systems and 3.3-V to 5-V translation. This flexibility makes it a valuable addition to various electronics projects and designs.

Features

  • Operates From 1.65 V to 5.5 V
  • Inputs Accept Voltages to 5.5 V
  • Max tpd of 4.2 ns at 3.3 V
  • Low Power Consumption, 10-μA Max ICC

Applications

The SN74LVC1G08DRLR is designed for a vast array of applications. It is commonly used in the design and development of consumer electronics, communication devices, and medical equipment. It is also suitable for use in server farms, data centers, and other high-performance computing environments.

Quality and Reliability

As with all Texas Instruments products, the SN74LVC1G08DRLR is designed to deliver high-quality performance and reliable operation. The chip is thoroughly tested for quality and performance, ensuring that it meets the high standards that customers expect from Texas Instruments. It is also backed by the company's comprehensive support and warranty policies.

With its advanced features and flexible operation, the SN74LVC1G08DRLR is an excellent choice for designers and engineers seeking high-performance, low-power solutions for their electronics projects.
