The TLV170 family of single-supply, rail-to-rail output operational amplifiers from Texas Instruments represents a remarkable blend of high-performance specifications ideally suited for a wide range of applications. The TLV170IDBVR variant is a single op-amp version, housed in a compact SOT-23-5 package, which is perfect for space-constrained applications.

Key Features

• Supply Voltage Range: The device operates over a broad supply voltage range of 2.7 V to 36 V, or ±1.35 V to ±18 V for split-supply operations, making it versatile for both low and high-voltage applications.
• Output Swing: Featuring rail-to-rail output, the TLV170IDBVR provides a wide dynamic range, which is essential for maximizing signal amplitude and improving signal-to-noise ratios.
• Low Quiescent Current: With a quiescent current of only 500 µA per channel, it offers a great balance between power consumption and performance, suitable for battery-powered devices.
• Robust Design: The device boasts a robust design with a wide temperature range of -40°C to 125°C, making it reliable for industrial applications.
• No Phase Reversal: The op-amp is designed to prevent phase reversal when the input voltage exceeds the power supply rails, providing stable operation for critical applications.

Applications

The TLV170IDBVR is ideal for a multitude of applications including sensor interfacing, active filtering, and low-side current sensing. Its ability to operate at low voltages makes it suitable for portable and battery-powered electronics, while its high-voltage capabilities allow it to be used in industrial control systems and automotive electronics.

Quality and Reliability

As with all Texas Instruments products, the TLV170IDBVR is manufactured to the highest quality standards, ensuring reliability and performance consistency. The device is RoHS compliant and is designed to meet the rigorous demands of extended industrial temperature ranges.

Ordering Information

The product is available in a small SOT-23-5 package, with the orderable part number TLV170IDBVR. For detailed specifications, application notes, and additional resources, please refer to the official Texas Instruments product page and datasheets.
