TPS2065D

Part No TPS2065D
Manufacturer Texas Instruments
Catalog PMIC - Power Distribution Switches, Load Drivers
Description CURRENT-LIMITED, POWER-DISTRIBUTION SWITCHES | IC POWER DIST SWITCH 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Switch Type General Purpose
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Load Voltage (V) 2.7V ~ 5.5V
Supply Voltage Not Required
Current - Output (Maximum) 1A
Rds On 70mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Temperature Range - Operating -40°C ~ 125°C
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number TPS2065
Manufacturer Pack Quantity 75
MSL Level 1 (Unlimited)
Win Source Part Number 1272143-TPS2065D
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management, Motor Drive & Control
Ultra Librarian 3D Model Ultra Librarian TPS2065D CAD Model

Description

Introducing the TPS2065D Power Distribution Switch from Texas Instruments

Enhance your electronic designs with the high-performance TPS2065D power distribution switch from Texas Instruments, a leading name in the semiconductor industry. This advanced component is engineered to provide efficient power management solutions that cater to a wide range of applications.

The TPS2065D is a single-channel, current-limited, power distribution switch designed for USB and other applications. It operates over an input voltage range of 2.7V to 5.5V, making it versatile for both 3.3V and 5V systems. The device is capable of delivering up to 1A of continuous current, which ensures reliable performance for connected peripherals.

Key Features of the TPS2065D

  • Current Limiting: The device provides a precise current limit to protect the system from overcurrent conditions. This feature helps to prevent damage to both the power switch and the downstream components.
  • Thermal Shutdown: With an integrated thermal shutdown mechanism, the TPS2065D prevents overheating by automatically turning off when the junction temperature exceeds the thermal shutdown threshold.
  • Under-Voltage Lockout (UVLO): The UVLO feature ensures that the device operates at the appropriate voltage levels, enhancing system reliability by preventing undervoltage operation.
  • Fast Transient Response: The TPS2065D has been optimized for fast transient response, which is essential for maintaining stable operation during sudden load changes.
  • Reverse Voltage Protection: Users can benefit from the built-in reverse voltage protection, which safeguards the system against potential damage from incorrect power supply connections.

Applications of the TPS2065D

The versatility of the TPS2065D makes it suitable for a variety of applications, including:

  • USB hubs and peripherals
  • Hot-swap supplies
  • Portable consumer electronics
  • Power management for battery-powered devices

With its robust protection features and reliable performance, the TPS2065D from Texas Instruments stands out as an essential component for designers looking to enhance the power management capabilities of their electronic projects. Its small package size also makes it an ideal choice for space-constrained applications.

Invest in the TPS2065D for your next design to ensure efficient and safe power distribution, backed by the quality and support of Texas Instruments.
