Product Overview: TPS3307-33DGN

The TPS3307-33DGN is a sophisticated, triple-supply voltage supervisor designed by Texas Instruments to ensure the reliability of digital systems such as microprocessors, microcontrollers, and DSPs. This integrated circuit (IC) is specifically crafted to monitor three different supply voltages, providing a high degree of precision and functionality in a single package.

Enclosed in an 8-pin MSOP (Mini Small Outline Package), the TPS3307-33DGN is engineered for space-constrained applications. It offers a fixed-sense threshold voltage of 3.3V for one of the monitored supplies, while the other two are adjustable, allowing for versatile use across various voltage levels. This flexibility makes it suitable for a broad range of applications, from industrial control systems to consumer electronics.

Key Features:

• Voltage Supervision: Precise monitoring of three supply voltages, with one fixed 3.3V detector and two adjustable voltage detectors.
• Low Power Consumption: Designed for energy efficiency, it operates with a very low quiescent current, making it ideal for battery-powered devices.
• Reset Time Delay: Features a programmable time delay for the reset output, ensuring reliable system reset and initialization.
• High Accuracy: Offers high threshold accuracy which ensures the system operates within safe voltage levels.
• Temperature Range: Operates over a wide temperature range, suitable for industrial and automotive environments.

Applications:

• Industrial Control Systems
• Telecommunication Equipment
• Portable/Battery-Powered Devices
• Computing Devices
• Automotive Systems

The TPS3307-33DGN is a testament to Texas Instruments' commitment to providing innovative and reliable solutions for power management challenges. With its comprehensive feature set and robust design, it is an essential component for systems that require meticulous voltage supervision to maintain operational integrity and prevent damage due to irregular supply voltages.
