TPS61256YFFT

Part No TPS61256YFFT
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BOOST 5V 1.9A SYNC 9DSBGA
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Up
Topology Boost
Output Type Fixed
Number of Outputs 1
Minimum Input Voltage 2.5V
Maximum Input Voltage 4.85V
Nominal Output Voltage (Min/Fixed) 5V
Output Current 1.9A (Switch)
Frequency - Switching 3.5MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 9-DSBGA (1.2x1.3)
Win Source Part Number 213394-TPS61256YFFT
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TPS61256YFFT CAD Model

Description

The TPS61256YFFT from Texas Instruments is a high-efficiency, synchronous boost converter that is designed to provide a compact and reliable power solution for portable and battery-powered applications. This advanced power management integrated circuit (PMIC) is capable of stepping up lower voltage levels to a desired higher output voltage, ensuring that devices can operate effectively even when the battery voltage drops below the nominal operating level.

Key Features

  • Wide Input Voltage Range: The TPS61256YFFT operates with an input voltage range from 2.3V to 5.5V, making it suitable for a wide array of battery technologies, including Li-Ion, Li-Polymer, and alkaline batteries.
  • Adjustable Output Voltage: The output voltage can be configured from 2.5V up to 5.5V, allowing for flexibility in design to meet the needs of various applications.
  • High Efficiency: With synchronous rectification and a 1.5MHz fixed switching frequency, the converter achieves high efficiency across the full load range.
  • Power Save Mode: To optimize efficiency at light loads, the TPS61256YFFT includes a Power Save Mode that reduces quiescent current and maintains high efficiency.
  • Protection Features: The device includes over-temperature and over-current protection, enhancing the safety and reliability of the end application.
  • Compact Package: Available in a small 2x2mm 9-pin SON package, the TPS61256YFFT is ideal for space-constrained applications.

Applications

The versatile nature of the TPS61256YFFT makes it an excellent choice for a range of applications, including but not limited to:

  • Portable and wearable electronics
  • Smartphones and tablets
  • Wireless speakers and headphones
  • Medical devices
  • IoT devices

Conclusion

With its wide input voltage range, adjustable output voltage, and high efficiency, the TPS61256YFFT from Texas Instruments is a robust power solution that can be tailored to meet the specific needs of a variety of portable devices. Its compact size and comprehensive protection features make it an ideal choice for designers looking to maximize performance while minimizing space and ensuring device safety.
