Same model may have multiple batches, images only for reference.

TS3A4742DCNR

Name: TS3A4742DCNR
Brand: Texas Instruments
SKU: 381331
Availability: InStock
Rating: 5 (223 reviews)

Part No	TS3A4742DCNR
Manufacturer	Texas Instruments
Catalog	Interface - Analog Switches, Multiplexers, Demultiplexers
Description	IC SWITCH DUAL SPST SOT23-8
Datasheet	TS3A4742DCNR Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $1.1167

Quantity

Unit Price

Ext. Price

35+

$1.4560

$50.960

85+

$1.1950

$101.575

130+

$1.1570

$150.410

180+

$1.1200

$201.600

235+

$1.0830

$254.505

310+

$0.9710

$301.010

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 20,470 pieces

MOQ: 35 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Switch Circuit	SPST - NC
Number of Circuits	2
Max On Resistance	900 mOhm
Channel-to-Channel Matching (ΔRon)	30 mOhm
Single Supply Voltage (V+)	1.6 V to 3.6 V
Max Switch Time (Ton,Toff)	14ns, 9ns
-3db Bandwidth	125MHz
Charge Injection	3pC
Channel Capacitance(CS off, CD off)	23pF, 20pF
Max Leakage Current (IS off)	2nA
Crosstalk	-95dB @ 1MHz
Temperature Range - Operating	-40°C to 85°C (TA)
Case / Package	SOT-23-8
Win Source Part Number	035065-TS3A4742DCNR
Popularity	Medium
Fake Threat In the Open Market	46 pct.
Supply and Demand Status	Limited
Alternative Parts (Cross-Reference)	MAX4742EKA+T; AS1742H-T; TS3A4742DGKRG4;

Description

Product Overview: Texas Instruments TS3A4742DCNR

The Texas Instruments TS3A4742DCNR is a cutting-edge, low-voltage, dual single-pole double-throw (SPDT) analog switch designed to provide high-performance switching capabilities in a variety of electronic applications. This versatile component is well-suited for use in both portable and stationary electronics due to its low power consumption and broad operating voltage range.

Key Features

Low On-State Resistance: The TS3A4742DCNR offers a low on-state resistance (typically 1 ohm), which ensures minimal signal distortion and power loss, enhancing overall system efficiency.
Wide Operating Voltage Range: This analog switch operates over a wide voltage range of 1.65V to 5.5V, making it compatible with various logic levels and suitable for battery-powered devices.
High Bandwidth: With a bandwidth greater than 300 MHz, the device can handle high-speed signals without compromising signal integrity, making it ideal for audio, video, and data applications.
Low Power Consumption: Its low power consumption is critical for extending battery life in portable devices, ensuring that the TS3A4742DCNR is an energy-efficient choice for modern electronic designs.
Break-Before-Make Switching: The switch provides break-before-make switching functionality, which prevents unwanted short circuits between channels during switching transitions.

Applications

The TS3A4742DCNR is suitable for a wide range of applications, including but not limited to:

Signal routing and multiplexing in audio and video equipment
Data acquisition systems
Communication devices
Portable instrumentation
Medical equipment

Package and Quality

Encased in a compact 10-pin VSSOP package, the TS3A4742DCNR is designed to occupy minimal board space, which is essential for space-constrained applications. Texas Instruments is known for its commitment to quality, and this product is no exception. It adheres to high manufacturing standards, ensuring reliability and performance consistency across various conditions and use cases.

In summary, the TS3A4742DCNR from Texas Instruments is a highly reliable and efficient solution for designers looking to incorporate precise and energy-saving analog switching into their electronic systems.
