TS3USB30ERSWR

Name: TS3USB30ERSWR
Brand: Texas Instruments
SKU: 381382
Availability: InStock
Rating: 5 (735 reviews)

Part No	TS3USB30ERSWR
Manufacturer	Texas Instruments
Catalog	Interface - Analog Switches - Special Purpose
Description	IC USB SWITCH DUAL 1X2 10UQFN
Datasheet	TS3USB30ERSWR Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $0.4400

Quantity

Unit Price

Ext. Price

90+

$0.5820

$52.380

210+

$0.4780

$100.380

325+

$0.4630

$150.475

450+

$0.4480

$201.600

580+

$0.4330

$251.140

775+

$0.3880

$300.700

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 38,400 pieces

MOQ: 90 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Applications	USB
Switch Circuit	DPDT
Number of Channels	1
Max On Resistance	10 Ohm
Single Supply Voltage (V+)	3 V to 4.3 V
-3db Bandwidth	900MHz
Features	Bi-Directional, USB 2.0
Temperature Range - Operating	-40°C to 85°C (TA)
Case / Package	10-UQFN (1.8x1.4)
Win Source Part Number	035097-TS3USB30ERSWR
Is this a common-used part?	Yes
Popularity	High
Fake Threat In the Open Market	62 pct.
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Portable Devices, Consumer Electronics
Family Name	TS3USB30E
Introduction Date	March 01, 2008
ECCN	EAR99
Country of Origin	China, Thailand
Halogen Free	Compliant
Estimated EOL Date	2028
Alternative Parts (Cross-Reference)	MAX4745ELB; MAX4736ELB+; MAX4745HELB;

Description

Product Overview: TS3USB30ERSWR from Texas Instruments

The TS3USB30ERSWR is a high-performance, low-power, single-lane USB 2.0 high-speed multiplexer/demultiplexer (mux/demux) switch from Texas Instruments. This versatile component is designed to switch a differential or single-ended signal to one of two locations in mobile applications, where minimizing power consumption and extending battery life are critical.

Key Features

USB 2.0 Compatibility: The TS3USB30ERSWR is fully compliant with the USB 2.0 standard, providing high-speed data transfer rates up to 480 Mbps.
Low On-Capacitance and On-Resistance: This device offers low on-capacitance (C_ON) and on-resistance (R_ON), which is essential for maintaining signal integrity, reducing insertion loss, and ensuring minimal impact on the data throughput.
Single Supply Operation: It operates from a single supply voltage in the range of 2.3 V to 4.3 V, which allows for easy integration into various system designs without the need for level shifting or external components.
ESD Protection: The device features ±8 kV IEC contact discharge and ±15 kV air-gap discharge protection on the D+ and D- pins, safeguarding the switch against electrostatic discharge events.
Space-Saving Package: The TS3USB30ERSWR comes in a compact UQFN-10 package, which is ideal for space-constrained applications such as smartphones, tablets, and other portable electronics.

Applications

The TS3USB30ERSWR is suitable for a wide range of applications, including but not limited to:

Mobile Phones and Smart Devices
Portable Media Players
Notebook and Desktop Computers
USB Peripheral Devices
Docking Stations

Conclusion

In conclusion, the TS3USB30ERSWR from Texas Instruments is an excellent choice for designers looking to incorporate a reliable USB 2.0 switch into their products. Its low power consumption, robust ESD protection, and space-saving design make it a versatile component for a multitude of USB-based applications.
