6N137F Real Image 6N137F Real Image
Same model may have multiple batches, images only for reference.
6N137F Real Image 6N137F Real Image
6N137F Real Image 6N137F Real Image
Same model may have multiple batches, images only for reference.

6N137F

Part No 6N137F
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Logic Output
Description OPTOISO 2.5KV 1CH OPEN COLL 8DIP
Datasheet
6N137F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 200V/μs, 500V/μs (Typ)
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 30ns, 30ns
Forward Voltage 1.65V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 1006827-6N137F
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 6N137F CAD Model

Description

The 6N137F is a through-hole optocoupler manufactured by Toshiba Semiconductor and Storage.

  • Output Type: Open collector
  • Maximum Data Rate: 10MBd
  • Forward Voltage: 1.65V
  • Input Type: DC
  • Inputs on Side 1: 1
  • Inputs on Side 2: 0
  • Common Mode Transient Immunity: 200V/μs (typical 500V/μs)
  • Propagation Delay tpLH and tpHL Maximum: 75ns
  • Isolation Voltage: 2500Vrms
  • Category: Isolator
  • Status: Active
  • Operating Temperature Range: 0°C to 70°C
  • Supply Voltage Operating Range: 4.5V to 5.5V
  • Rise and Fall Time: 30ns
  • Channel Output Current: 50mA
  • Continuous Forward Current Maximum: 20mA
  • Supply and Demand Status: Balanced
