TB6559FG(O,8,EL) Real Image1 TB6559FG(O,8,EL) Real Image2 TB6559FG(O,8,EL) Real Image3 TB6559FG(O,8,EL) Real Image4
Same model may have multiple batches, images only for reference.
TB6559FG(O,8,EL) Real Image1 TB6559FG(O,8,EL) Real Image2 TB6559FG(O,8,EL) Real Image3 TB6559FG(O,8,EL) Real Image4
TB6559FG(O,8,EL) Real Image1 TB6559FG(O,8,EL) Real Image2 TB6559FG(O,8,EL) Real Image3 TB6559FG(O,8,EL) Real Image4
Same model may have multiple batches, images only for reference.

TB6559FG(O,8,EL)

Part No TB6559FG(O,8,EL)
Manufacturer Toshiba Semiconductor and Storage
Catalog Interface - Specialized
Description Full Bridge DC Motor Driver 10V to 30V 16-Pin HSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Collector Emitter Voltage (VCEO) 30 V
Height 2.3 mm
Length 13 mm
Max Collector Current 2.5 A
Maximum Operating Temperature 85 °C
Max Power Dissipation 1.4 W
Max Supply Voltage 30 V
Min Operating Temperature -30 °C
Min Supply Voltage 10 V
Motor Type Brushed
Mount Surface Mount
Number of Outputs 1
Number of Pins 16
Operating Supply Current 4 mA
Output Current 1 A
REACH SVHC No SVHC
RoHS Compliant
Termination SMD/SMT
Width 6.4 mm
Win Source Part Number 985933-TB6559FG(O,8,EL)
Categories Interface - Specialized
Manufacturer Toshiba Semiconductor and Storage
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian TB6559FG(O,8,EL) CAD Model

Description

The Toshiba Semiconductor and Storage TB6559FG(O,8,EL) is a low-popularity electronic component that can be used for various applications.

  • Type: surface mount motor driver
  • Maximum Collector-Emitter Voltage: 30V
  • Maximum Collector Current: 2.5A
  • RoHS Compliant: Yes
  • Maximum Power Dissipation: 1.4W
  • Operating Temperature: -30 °C to 85 °C
  • Supply and Demand Status: shortage
  • Win Source Part Number: 985933-TB6559FG(O,8,EL)
