TC4001BFTEL Toshiba Semiconductor and Storage
Same model may have multiple batches, images only for reference.

TC4001BFTEL

Part No TC4001BFTEL
Manufacturer Toshiba Semiconductor and Storage
Catalog Logic - Gates and Inverters
Description IC GATE NOR 4CH 2-INP 14TSSOP
Datasheet
TC4001BFTEL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Logic Type NOR Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 3 V to 18 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 3.4mA, 3.4mA
Logic Level - Low 1.5 V to 4 V
Logic Level - High 3.5 V to 11 V
Max Propagation Delay @ V, Max CL 80ns @ 15V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOP
Dimension 14-SOIC (0.209", 5.30mm Width)
Win Source Part Number 1105863-TC4001BFTEL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TC4001BFTEL CAD Model

Description

The Toshiba Semiconductor and Storage TC4001BFTEL is a NOR gate logic type integrated circuit with four circuits and two inputs.

  • Current Output: 3.4mA
  • Quiescent Current: 1μA
  • Logic Level Low: 1.5V to 4V
  • Logic Level High: 3.5V to 11V
  • Package: 14-SOP
  • Dimension: 14-SOIC (0.209", 5.30mm Width)
  • Supply Voltage Range: from 3V to 18V
  • Operating Temperature Range: from -40°C to 85°C
  • Supply and Demand Status: balanced
