TLP116A Toshiba Semiconductor and Storage TLP116A real image
Same model may have multiple batches, images only for reference.
TLP116A Toshiba Semiconductor and Storage TLP116A real image
TLP116A Toshiba Semiconductor and Storage TLP116A real image
Same model may have multiple batches, images only for reference.

TLP116A

Part No TLP116A
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV PUSH PULL SO6-5
Datasheet
TLP116A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 10mA
Data Rate 20MBd
Propagation Delay tpLH / tpHL (Max) 60ns, 60ns
Rise and Fall Time 15ns, 15ns
Forward Voltage 1.58V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 6-SO, 5 Lead
Win Source Part Number 056664-TLP116A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TLP116A CAD Model

Description

The electronic component with ID 377173 is an isolator manufactured by Toshiba Semiconductor and Storage.

  • Win Source Part Number: 056664-TLP116A
  • Package: 6-SO, 5 Lead
  • Supply and demand status: balanced
  • Output type: push-pull, totem pole
  • Data rate: 20MBd
  • Forward voltage: 1.58V
  • Common mode transient immunity: 10kV/μs
  • Propagation delay tpLH / tpHL (Max): 60ns, 60ns
  • Isolation voltage: 3750Vrms
  • Input type: DC
  • Channel: 1
  • Side 1 Inputs: 1
  • Side 2 Inputs: 0
  • Temperature range: -40°C to 100°C
  • Operating supply voltage: 4.5 V to 5.5 V
  • Rise and fall time: 15ns, 15ns
  • Channel output current: 10mA
  • Continuous forward current: 20mA
