Same model may have multiple batches, images only for reference.

TLP280-1GB

Name: TLP280-1GB
Brand: Toshiba Semiconductor and Storage
SKU: 370275
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	TLP280-1GB
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optoisolator Transistor Output 2500Vrms 4 Channel 16-SOP
Datasheet	TLP280-1GB Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators
Family	Optoisolators - Transistor, Photovoltaic Output
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Tube
Number of Channels	4
Voltage - Isolation	2500Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	600% @ 5mA
Turn On / Turn Off Time (Typ)	3μs, 3μs
Rise / Fall Time (Typ)	2μs, 3μs
Input Type	AC, DC
Output Type	Transistor
Voltage - Output (Max)	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.15V
Current - DC Forward (If) (Max)	50mA
Vce Saturation (Max)	400mV
Operating Temperature Range	-55°C ~ 100°C
Mounting Style	SMD/SMT
Package	16-SOIC (0.173", 4.40mm Width)
Manufacturer Device Package	16-SOP
Win Source Part Number	218133-TLP280-1GB
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian TLP280-1GB CAD Model

Alternative Products

Description

The Toshiba Semiconductor and Storage TLP280-1GB is a medium popularity electronic component that is limited in supply and demand.

Type: Optoisolator with a transistor photovoltaic output
Package: 16-SOIC
Channels: Four
Output Current: Up to 50mA
Voltage Isolation: 2500Vrms
Current Transfer Ratio: 100 percent @ 5mA
