Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Optoelectronics - LED Emitters - Infrared, UV, Visible
Mfr TT Electronics
Package Bulk
Product Status Active
Type Infrared (IR)
Current - DC Forward (If) (Max) 100mA
Wavelength 890nm
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 18°
Orientation Top View
Temperature Range - Operating -65°C ~ 125°C (TA)
Mounting Type Through Hole
Package / Case TO-46-2 Lens Top Metal Can
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 650437-OP232
Ultra Librarian 3D Model Ultra Librarian OP232 CAD Model

Description

The TT Electronics LED Emitter is an infrared component that provides reliable performance in various electronic applications.

  • Orientation: top view
  • Current Rating: 100mA
  • Forward Voltage: 2V
  • Viewing Angle: 18°
  • Wavelength: 890nm
  • Mounting: through-hole
  • Classification: EAR99
