Products specifications Report Issue?

Manufacturer UTC
Win Source Part Number 355722-TBA820ML
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TBA820ML CAD Model

Description

The TBA820ML is a monolithic integrated audio amplifier designed for low voltage applications. It is commonly used as a low-power amplifier in portable audio devices and other battery-powered applications. This amplifier is characterized by its simple design, low external component count, and reasonable power output for its size and power consumption.

Applications:

  • Portable radios
  • Battery-powered audio amplifiers
  • Small audio projects
  • Intercom systems

Features:

  • Low supply voltage operation
  • Few external components required
  • Low quiescent current
  • Internal thermal protection
  • Fixed gain

Benefits:

  • Extended battery life due to low power consumption.
  • Simplified circuit design.
  • Protection against overheating.
  • Compact size.

Additional Details:

The TBA820ML typically operates on a supply voltage between 3V and 16V. The output power is dependent on the supply voltage and load impedance. It is commonly available in a DIP (Dual In-line Package) or similar through-hole package. For precise electrical characteristics such as output power, voltage gain, total harmonic distortion, and recommended application circuit configurations, refer to the official UTC datasheet.
