5KP40A-E3/54 Real Image 5KP40A-E3/54 label picture 5KP40A-E3/54 real image
Same model may have multiple batches, images only for reference.
5KP40A-E3/54 Real Image 5KP40A-E3/54 label picture 5KP40A-E3/54 real image
5KP40A-E3/54 Real Image 5KP40A-E3/54 label picture 5KP40A-E3/54 real image
Same model may have multiple batches, images only for reference.

5KP40A-E3/54

Part No 5KP40A-E3/54
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS Diode Single Uni-Dir 40V 5KW 2-Pin Case P-600 T/R / TVS DIODE 40VWM 64.5VC P600
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 40V
Minimum Breakdown Voltage 44.4V
Max Clamping Voltage 64.5V
Peak Pulse Current(Ippm) 77.5A
Power Dissipation - Pd 5000W (5kW)
Applications General Purpose
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package P600
Win Source Part Number 1006388-5KP40A-E3/54
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name 5KP40A
Introduction Date October 27, 2004
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian 5KP40A-E3/54 CAD Model

Description

The Vishay 5KP40A-E3/54 is a zener diode with a peak pulse current (Ippm) of 77.5A and a power dissipation of 5000W (5kW).

  • Peak Pulse Current (Ippm): 77.5A
  • Power Dissipation: 5000W (5kW)
  • Minimum Breakdown Voltage: 44.4V
  • Max Clamping Voltage: 64.5V
  • STAND-OFF voltage (Vwm): 40V
  • Package: P600
