BZG03C240TR Real Image BZG03C240TR real image15237
Same model may have multiple batches, images only for reference.
BZG03C240TR Real Image BZG03C240TR real image15237
BZG03C240TR Real Image BZG03C240TR real image15237
Same model may have multiple batches, images only for reference.

BZG03C240TR

Part No BZG03C240TR
Manufacturer Vishay
Catalog Diodes - Zener - Single
Description DIODE ZENER 1.25W DO214AC
Datasheet
BZG03C240TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 240V
Maximum Power Dissipation 1.25W
Impedance (Max) (Zzt) 850 Ohm
Current - Reverse Leakage @ Vr 1μA @ 180V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 500mA
Temperature Range - Operating -65°C to 150°C
Mounting SMD (SMT)
Case / Package DO-214AC
Win Source Part Number 1025831-BZG03C240TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name BZG03C240
Introduction Date October 07, 2003
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date Obsolete
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian BZG03C240TR CAD Model

Description

The Vishay BZG03C240TR is a Zener diode with a maximum forward voltage of 1.2V at 500mA and a reverse leakage current of 1μA at 180V.

  • Maximum Forward Voltage: 1.2V @ 500mA
  • Reverse Leakage Current: 1μA @ 180V
  • Zener Voltage: 240V
  • Maximum Impedance: 850 Ohm
  • Power Dissipation: 1.25W
  • Operating Temperature Range: -65°C to 150°C
  • Package: DO-214AC
  • Package Quantity: 1,500 pieces
  • Popularity: High
  • Supply and Demand Status: Balance
  • Halogen-Free: No
  • ECCN: Unknown
