CRCW12060000Z0EA Texas Instruments
Same model may have multiple batches, images only for reference.

CRCW12060000Z0EA

Part No CRCW12060000Z0EA
Manufacturer Vishay
Catalog Chip Resistor - Surface Mount
Description RES SMD 0 OHM JUMPER 1/4W 1206
Datasheet
CRCW12060000Z0EA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors - Chip Resistor - Surface Mount
Mfr Vishay
Series CRCW
Package Tape & Reel
Product Status Active
Resistance 0 Ohms
Tolerance Jumper
Composition Thick Film
Features Automotive AEC-Q200
Temperature Range - Operating -55°C ~ 155°C
Package / Case 1206 (3216 Metric)
Supplier Device Package 1206
Ratings AEC-Q200
Size / Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max) 0.024" (0.60mm)
Number of Terminations 2
Base Product Number CRCW1206
Standard Package 5,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8533.21.0030
Win Source Part Number 580363-CRCW12060000Z0EA
Ultra Librarian 3D Model Ultra Librarian CRCW12060000Z0EA CAD Model

Description

The CRCW12060000Z0EA is a chip resistor from Vishay's CRCW series.

  • Size: 0.126" L x 0.063" W (3.20mm x 1.60mm)
  • Height: 0.024" (0.60mm)
  • Application: automotive
  • Standard: AEC-Q200
  • Composition: thick film
  • Terminations: two
  • Tolerance: jumper
  • Resistance: 0 Ohms
  • Package: tape & reel
  • Standard Package Size: 5,000 pcs
  • Operating Temperature: -55°C to 155°C
  • Status: active
