The ETL0806FP-M3 is a surface-mount Schottky Barrier Rectifier from Vishay. This rectifier is designed for high-frequency applications where efficiency and low forward voltage drop are crucial.

Applications

• Switching Power Supplies: Used in the output rectification stage to improve efficiency.
• DC-DC Converters: Employed for efficient voltage conversion in various electronic devices.
• Freewheeling Diodes: Protects inductive loads from voltage spikes during switching.
• Polarity Protection: Prevents damage from reverse polarity connections.

Features

• Low Forward Voltage Drop: Minimizes power loss and improves overall efficiency.
• High Surge Current Capability: Can withstand high current surges without failure.
• High-Frequency Operation: Suitable for use in high-frequency circuits.
• Surface Mount Package: Allows for automated assembly and reduces board space.
• RoHS Compliant: Meets environmental standards for hazardous substances.

Benefits

• Increased Efficiency: The low forward voltage drop reduces power dissipation, leading to higher efficiency in power supplies and converters.
• Improved Reliability: The high surge current capability ensures robust performance even under demanding conditions.
• Reduced Size and Weight: The surface-mount package allows for compact designs.
• Simplified Assembly: Surface mount design facilitates automated assembly processes, reducing manufacturing costs.

Additional Details

Technical Specifications:

• Voltage - DC Reverse (Vr) (Max): 60V
• Current - Average Rectified (Io): 8A
• Voltage - Forward (Vf) (Max) @ If: 700mV @ 8A
• Current - Reverse Leakage @ Vr: 500 µA @ 60 V
• Operating Temperature - Junction: -65°C ~ 150°C
• Mounting Type: Surface Mount
• Package / Case: TO-277A, SMPC3.6

The ETL0806FP-M3 from Vishay provides a reliable and efficient solution for rectification needs in modern electronic devices.
