Same model may have multiple batches, images only for reference.

IHLP5050FDERR22M01

Name: IHLP5050FDERR22M01
Brand: Vishay
SKU: 1532183
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IHLP5050FDERR22M01
Manufacturer	Vishay
Catalog	Fixed Inductors
Description	FIXED IND 220NH 53A 0.7 MOHM SMD
Datasheet	IHLP5050FDERR22M01 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Type	Molded
Inductance	220 nH
Tolerance	±20%
Current Rating (Amps)	53 A
Current - Saturation (Isat)	112A
Shielding	Shielded
DC Resistance (DCR)	0.7mOhm Max
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting Type	Surface Mount
Case / Package	Nonstandard
Size / Dimension	0.520" L x 0.508" W (13.20mm x 12.90mm)
Height - Seated (Max)	0.256\
Package	Tape & Reel
Supply and Demand Status	Shortage
Win Source Part Number	1532183-IHLP5050FDERR22M01
Ultra Librarian 3D Model	Ultra Librarian IHLP5050FDERR22M01 CAD Model
