RGP02-20E-E3/54 Vishay RGP02-20E-E3/54 Real Image RGP02-20E-E3/54 label picture
Same model may have multiple batches, images only for reference.
RGP02-20E-E3/54 Vishay RGP02-20E-E3/54 Real Image RGP02-20E-E3/54 label picture
RGP02-20E-E3/54 Vishay RGP02-20E-E3/54 Real Image RGP02-20E-E3/54 label picture
Same model may have multiple batches, images only for reference.

RGP02-20E-E3/54

Part No RGP02-20E-E3/54
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Switching 2KV 0.5A 300ns 2-Pin DO-41 T/R / DIODE GEN PURP 2KV 500MA DO204
Datasheet
RGP02-20E-E3/54 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 2000V (2kV)
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 1.8V @ 100mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 300ns
Current - Reverse Leakage @ Vr 5μA @ 2000V
Mounting Through Hole
Case / Package DO-204AL (DO-41)
Operating Temperature - Junction -65°C to 175°C
Win Source Part Number 027409-RGP02-20E-E3/54
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name RGP02-20E
Introduction Date June 24, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian RGP02-20E-E3/54 CAD Model

Description

The Vishay RGP02-20E-E3/54 is a through-hole DO-204AL (DO-41) package standard diode with a maximum reverse voltage of 2000V and an average rectified current (Io) of 500mA.

  • Forward Voltage (Vf): 1.8V @ 100mA
  • Reverse Recovery Time (trr): 300ns
  • Current Reverse Leakage: 5µA @ 2000V
  • Family Name: RGP02-20E
  • Popularity: high
  • Supply and Demand Status: limited
  • Used in: discrete semiconductor products, such as FETs, MOSFETs, and other applications
  • Speed: fast recovery = 200mA (Io)
