VS-6ESH01-M3/86A Real Image VS-6ESH01-M3/86A real image15080
Same model may have multiple batches, images only for reference.
VS-6ESH01-M3/86A Real Image VS-6ESH01-M3/86A real image15080
VS-6ESH01-M3/86A Real Image VS-6ESH01-M3/86A real image15080
Same model may have multiple batches, images only for reference.

VS-6ESH01-M3/86A

Part No VS-6ESH01-M3/86A
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE 100V 6A TO277A / Rectifier Diode Switching 100V 6A 25ns 3-Pin(2+Tab) SMPC T/R
Datasheet
VS-6ESH01-M3/86A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Series FRED Pt
Packaging Reel package
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 100V
Current - Average Rectified (Io) 6A
Voltage - Forward (Vf) (Maximum) @ If 940mV @ 6A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 22ns
Current - Reverse Leakage @ Vr 2μA @ 100V
Mounting SMD
Package TO-277, 3-PowerDFN
Manufacturer Package TO-277A (SMPC)
Operating Temperature - Junction -65°C ~ 175°C
Win Source Part Number 799204-VS-6ESH01-M3/86A
Popularity Medium
Supply and Demand Status Limited
Family Name VS-6ESH01
Introduction Date October 07, 2014
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian VS-6ESH01-M3/86A CAD Model

Description

The Vishay Semiconductor Diodes Division VS-6ESH01-M3/86A is a standard diode from Vishay Semiconductor Diodes Division.

  • Current: 6A
  • Voltage: 100V
  • Series: FRED Pt
  • Package: TO-277, 3-PowerDFN
  • Mounting: SMD
  • Forward Voltage: 940mV @ 6A
  • Reverse Leakage Current: 2μA @ 100V
  • Recovery Time: 200mA (Io)
  • Reverse Recovery Time (trr): 22ns
  • Operating Temperature: -65°C to 175°C
  • Package: TO-277A (SMPC)
  • Alternative Parts: VS-6ESH01HM3/86A, VS-6ESH01HM3/87A, MV1N5809U4, MX1N5809U4
  • Introduction Date: October 07, 2014
  • ECCN: EAR99
  • Estimated EOL Date: 2027
