Same model may have multiple batches, images only for reference.

VS-MURB1520TRLPBF

Name: VS-MURB1520TRLPBF
Brand: Vishay
SKU: 790275
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	VS-MURB1520TRLPBF
Manufacturer	Vishay
Catalog	Diodes, Rectifiers - Single
Description	DIODE GEN PURP 200V 15A D2PAK / Rectifier Diode Switching 200V 15A Automotive 3-Pin(2+Tab) D2PAK T/R
Datasheet	VS-MURB1520TRLPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay Semiconductor Diodes Division
Series	FRED Pt
Packaging	Reel package
Diode Type	Standard
Voltage - DC Reverse (Vr) (Maximum)	200V
Current - Average Rectified (Io)	15A
Voltage - Forward (Vf) (Maximum) @ If	1.05V @ 15A
Speed	Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr)	22ns
Current - Reverse Leakage @ Vr	10μA @ 200V
Mounting	SMD
Package	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Manufacturer Package	D2PAK
Operating Temperature - Junction	-65°C ~ 175°C
Win Source Part Number	790275-VS-MURB1520TRLPBF
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	800
Family Name	VS-MURB1520
Introduction Date	March 25, 2010
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian VS-MURB1520TRLPBF CAD Model

Alternative Products

Description

The Vishay Semiconductor Diodes Division VS-MURB1520TRLPBF is a FRED Pt diode.

Current Average Rectified (Io): 15A
Voltage Forward (Vf): 1.05V @ 15A (Maximum)
Reverse Recovery Time (trr): 22ns
Current - Reverse Leakage (Ir): 10μA @ 200V
Application: Discrete Semiconductor Products
Popularity: Medium
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting: Surface Mount
Fast Recovery Speed: 200mA (Io)
Operating Temperature: -65°C to 175°C
Manufacturer: Vishay Semiconductor Diodes Division
Win Source Part Number: 790275-VS-MURB1520TRLPBF
Packaging: Reel (800 per package)
