Same model may have multiple batches, images only for reference.

744771115

Name: 744771115
Brand: Wurth Electronics Inc
SKU: 807617
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

Part No	744771115
Manufacturer	Wurth Electronics Inc
Catalog	Fixed Inductors
Description	FIXED IND 15UH 3.75A 30 MOHM SMD / POWER-CHOKE WE-PD
Datasheet	744771115 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Würth Elektronik
Packaging	Reel
Type	Wirewound
Material - Core	Ferrite
Inductance	15μH
Tolerance	±20%
Current Rating (Amps)	3.75A
Current - Saturation	4.55A
Shielding	Shielded
DC Resistance (DCR)	30mOhm Max
Frequency - Self Resonant	16.6MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	1kHz
Mounting Style	SMD
Manufacturer Package	Nonstandard
Dimension	0.472" L x 0.472" W (12.00mm x 12.00mm)
Height - Seated (Maximum)	0.236" (6.00mm)
Manufacturer Pack Quantity	500
MSL Level	1 (Unlimited)
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	807617-744771115
Ultra Librarian 3D Model	Ultra Librarian 744771115 CAD Model

Alternative Products

Description

The 744771115 is a shielded wirewound inductor manufactured by Würth Elektronik.

Inductance: 15μH
Tolerance: ±20%
High Current: yes
Saturation Current: 4.55A
DC Resistance: 30mOhm
Self-Resonant Frequency: 16.6MHz
Packaging: nonstandard
Reel Quantity: 500
Supply and Demand: balanced
