Part No 2514-5002UG
Manufacturer 3M
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 14POS 2.54MM / Connector Header Through Hole, Right Angle 14 position 0.100" (2.54mm)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr 3M
Series 2500
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 14
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.243" (6.17mm)
Contact Length - Post 0.112" (2.84mm)
Insulation Height 0.338" (8.59mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 15.0µin (0.38µm)
Contact Finish - Post Tin-Lead
Contact Material Copper Alloy
Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features Keying Slot
Temperature Range - Operating -55°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 1.75A
Contact Finish Thickness - Post 200.0µin (5.08µm)
Base Product Number 2514
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 00054007827160,80610565063,05400782716
Standard Package 616
Win Source Part Number 1033521-2514-5002UG
Ultra Librarian 3D Model Ultra Librarian 2514-5002UG CAD Model

Description

The 3M 1033521-2514-5002UG is a male pin header with 14 positions and a keying slot feature.

  • Category: Rectangular connectors - headers, male pins
  • Series: 2500
  • Style: Board to board or cable
  • Pitch: 0.100 inches (2.54mm)
  • Contact Finish-Mating: Gold
  • Mounting Type: Through-hole, right angle
  • Shrouding: Shrouded - 4 wall
  • Current Rating: 1.75A
  • ECCN: EAR99
  • HTSUS Code: 8536.69.4040
  • Other Part Numbers: 2514-5002UG2514-5002-UG, 80001417171, 80610565063
  • Base Product Number: 2514
  • RoHS: Non-compliant
