929950-00 Real Image
Same model may have multiple batches, images only for reference.

929950-00

Part No 929950-00
Manufacturer 3M
Catalog Circular Connectors - Housings
Description SHORTING JUMPER UNPLATED BLK / 2 (1 x 2) Position Shunt Connector Black Open Top 0.100" (2.54mm) Unplated
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Shunts, Jumpers
Mfr 3M
Series 929
Package Bulk
Type Open Top
Gender Female Sockets
Number of Positions or Pins (Grid) 2 (1 x 2)
Pitch 0.100" (2.54mm)
Height 0.298" (7.57mm)
Contact Finish Unplated
Color Black
Material Flammability Rating UL94 V-0
Housing Material Polybutylene Terephthalate (PBT)
Current Rating (Amps) 1A
Base Product Number 929950
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8538.90.8180
Other Names 54007851240,929950,80-6200-8254-7,925250,929950-0,92995000,80-0013-8735-8,0-00-51115-60656-4,925250-R,929950-00-I,7100035747,5400785124,929950-0-I,80620082547,80001387358
Standard Package 2,000
Win Source Part Number 1041630-929950-00
Ultra Librarian 3D Model Ultra Librarian 929950-00 CAD Model

Description

The 1041630-929950-00 connector from 3M is a part of the 929 series.

  • Type: Open Top Shunt
  • Pitch: 0.100" (2.54mm)
  • Color: Black
  • Contact Finish: Unplated
  • Positions / Pins: 2
  • Grid: 1 x 2
  • Height: 0.298" (7.57mm)
  • Housing Material: Polybutylene Terephthalate (PBT)
  • Material Flammability Rating: UL94 V-0
  • Contact Type: Female Socket
  • Package: Bulk
  • Current Rating: 1A
  • REACH: Unaffected
  • Temperature Range: -55°C to 125°C
