Products specifications Report Issue?

Categories Uncategorized
Manufacturer ABOV
Popularity Low
Supply and Demand Status Balance
Win Source Part Number 830388-MC2302D
Ultra Librarian 3D Model Ultra Librarian MC2302D CAD Model

Description

The ABOV MC2302D is a microcontroller designed for a variety of embedded applications. It serves as the central processing unit in systems requiring control, data processing, and communication capabilities. ABOV microcontrollers are generally known for being cost-effective solutions targeted at a broad range of applications.

Applications

  • Remote Controls: Commonly used in remote controls for TVs, DVD players, and other consumer electronics.
  • Home Appliances: Found in washing machines, refrigerators, and other appliances for controlling motor functions, sensors, and user interfaces.
  • Toys and Games: Employed in electronic toys and games for controlling lights, sounds, and other interactive features.
  • Industrial Control: Can be used for basic automation, sensor data acquisition, and simple motor control.

Features

  • 8-bit Microcontroller Core: Features a standard 8-bit architecture that balances performance and efficiency.
  • Internal Memory: Includes Flash memory for program storage and RAM for data manipulation.
  • Communication Interfaces: Provides UART, SPI, and I2C interfaces for communicating with other devices.
  • Timers and Counters: Equipped with multiple timers and counters for generating PWM signals and timing events.
  • Analog-to-Digital Converter (ADC): Integrates an ADC for converting analog signals into digital values.
  • Low Power Consumption: Designed for low power consumption to extend battery life in portable applications.

Benefits

  • Cost-Effective: Offers a budget-friendly solution for embedded control needs.
  • Easy to Program: Uses industry standard programming tools and supports C language.
  • Versatile: Provides a range of peripheral options for connecting to external components.
  • Reliable Performance: Delivers consistent and stable operation in various environments.

The MC2302D operates within a voltage range suitable for many applications. Package options are generally available in DIP, SOIC, and QFP. It is programmed using standard C programming tools and debugged using in-circuit emulators. While specific memory sizes and clock speeds can vary, the device provides sufficient resources for the intended embedded applications.
