ABMM2-16.000MHZ-E2-T Real Image ABMM2-16.000MHZ-E2-T Real Image
Same model may have multiple batches, images only for reference.
ABMM2-16.000MHZ-E2-T Real Image ABMM2-16.000MHZ-E2-T Real Image
ABMM2-16.000MHZ-E2-T Real Image ABMM2-16.000MHZ-E2-T Real Image
Same model may have multiple batches, images only for reference.

ABMM2-16.000MHZ-E2-T

Part No ABMM2-16.000MHZ-E2-T
Manufacturer Abracon LLC
Catalog Oscillators
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators>Crystals
Mfr Abracon LLC
Series ABMM2
Package Tape & Reel
Type MHz Crystal
Frequency 16 MHz
Frequency Stability ±20ppm
Frequency Tolerance ±20ppm
Load Capacitance 18pF
ESR (Equivalent Series Resistance) 50 Ohms
Operating Mode Fundamental
Temperature Range - Operating -20°C ~ 70°C
Mounting SMD (SMT)
Package / Case 4-SMD, No Lead
Dimension 0.240" L x 0.142" W (6.00mm x 3.60mm)
Height - Seated (Max) 0.047" (1.20mm)
Other Names 2266-ABMM2-16.000MHZ-E2-T,535-9634-1,535-9634-2,ABMM216000MHZE2T,535-9634-6
Standard Package 1,000
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 1285007-ABMM2-16.000MHZ-E2-T
Ultra Librarian 3D Model Ultra Librarian ABMM2-16.000MHZ-E2-T CAD Model

Description

The Abracon LLC 1285007-ABMM2-16.000MHZ-E2-T is a surface mount crystal with a frequency of 16MHz and a frequency tolerance of ±20ppm.

  • Frequency: 16MHz
  • Frequency Tolerance: ±20ppm
  • Load Capacitance: 18pF
  • ESR: 50 Ohms
  • Height: 0.047 inches (1.20mm)
  • Package Size: 4-SMD, No Lead
  • Operating Temperature Range: -20°C to 70°C
  • REACH: Unaffected
  • Production Lead Time: 32 weeks
